The TH-12 is a passive two-way speaker designed for small to medium-sized theaters.
It integrates effortlessly into 5.1, 7.1, or Dolby Atmos sound systems, delivering consistent, high-quality surround sound, whether mounted on the sides, rear, or overhead.
At the heart of the TH-10 is a powerful 10" woofer, delivering solid low and mid-frequency performance. This is paired with a 1" compression driver and a 90° x 40° waveguide, ensuring wide, even coverage and detailed sound reproduction throughout the listening area.
With a built-in crossover and 500-watt power handling, the TH-12 offers both efficiency and high output. Its plug-and-play design and simple setup make it a convenient, professional-grade solution for immersive cinema sound.
Passive two-way design
12" woofer for extended low and mid-frequency performance
1" compression driver with 60° x 60° waveguide
Built-in crossover for smooth frequency response
500W power capacity
Compatible with 5.1, 7.1, and Dolby Atmos systems
Flexible mounting options: side, rear, or overhead
The TH-12 is ideal for cinema installations that demand powerful, immersive surround sound with reliable performance and easy integration.
Frequency Range : |
65Hz-22kHz |
Power handling : |
500W |
Nominal Impedance : |
8 Ohms |
Sensitivity @ 1 watt : |
100 dB |
Max SPL @ 1 meter : |
126 dB |
Dispersion : |
60°H x 60°V |
Components : |
LF: 1 x 12" low-mid driver with 3" VC |
|
HF: 1 x 3" VC compression driver |
Recommended Power : |
800 W |
Input Terminals : |
Push-in Terminals |
Enclosure : |
Wood |
Dimensions (WxDxH) : |
16.5" x 11.85" x 26.75" |
Weight : |
30 kg |
